Workflow documentation

A Workflow is a way to chain Actions. The syntax is similar to how async/await syntax works. A Workflow is also a specific type of Action, so you can chain Workflows in other Workflows.

Write a Workflow

A Workflow, same as an Action, has an init() method. A Workflow also has a define() method where you can write your flow of Actions.

export class MyWorkflow extends Workflow {
    define() {
        try {
            await this.do(
                'my-action',
                new MyAction().setArgument({
                    x: 1,
                })
            );
        } catch (err) {
            await this.do(
                'on-error-action',
                new OnErrorAction().setArgument({
                    x: 1,
                })
            );
        } finally {
            //....
        }
        return {
            x: 2,
        };
    }
}

The do method

Purpose

The do() method is used to declare an action to be executed within the workflow. It mimics the behavior of await in native JavaScript/TypeScript syntax to provide readable, sequential flow control.

However, do() is more complex than a normal asynchronous call. Behind the scenes, the orbits framework implements deterministic execution with built-in replayability. This means:

define() can be executed multiple times during the lifecycle of a workflow.
Each call to do() is idempotent: the action is only executed once.
On re-execution, previously completed do() calls return the stored result instead of re-running the action.

Point of attention: deterministic execution and async/await

Incorrect

export class BadWorkflow extends Workflow {
    define() {
        const search = await axios.get('https://google.com?search=test'); // ❌ Not deterministic
        if (search.length) {
            await this.do('step-a', new StepA());
        } else {
            await this.do('step-b', new StepB());
        }

        return { status: 'done' };
    }
}

Correct

export class CorrectWorkflow extends Workflow {
    define() {
        const search = await this.do('search', () => {
            axios.get('https://google.com?search=test');
        });

        if (search.length) {
            await this.do('step-a', new StepA());
        } else {
            await this.do('step-b', new StepB());
        }

        return { status: 'done' };
    }
}

Incorrect

export class BadWorkflow extends Workflow {
    define() {
        const now = Date.now(); // ❌ Not deterministic

        if (now % 2 === 0) {
            await this.do('step-a', new StepA());
        } else {
            await this.do('step-b', new StepB());
        }

        return { now };
    }
}

Correct

export class CorrectWorkflow extends Workflow {
    IBag: {
        now: number;
    };

    async init() {
        await super.init();
        if (!this.bag.now) {
            this.bag.now = Date.now();
        }
    }

    define() {
        if (this.bag.now % 2 === 0) {
            await this.do('step-a', new StepA());
        } else {
            await this.do('step-b', new StepB());
        }

        return { now: this.bag.now };
    }
}

Action Step definition

The do() method accepts an Action instance as its argument:

await this.do('step-a', new MyAction().setArgument({ some: 'argument' }));

The action will be persisted in the database and executed in an isolated context.

The result of the await will be the result of the action.
If the final action's state is ActionState.ERROR, the do() method will throw the error — allowing standard error handling using try/catch.

On the fly promise definition

The do() method also accepts a callback that returns a Promise.

await this.do('step-a', () => {
    return Promise.resolve();
});

await this.do('step-b', myAsyncFunction.bind('some', 'argument'));

The promise will be executed once and only once.
The result of the await will be the resolved value of the promise.
If an error occurs, it will be thrown by do() and can be handled via try/catch.

Dynamic definition

Dynamic definitions are useful when you need to pass non-serializable parameters, such as functions. Since actions are stored in the database, only JSONObject-compatible properties can be persisted. To pass methods or closures through the chain of actions, use the dynamicAction option:

const action = new MyAction();
// override a method of your action
action.getCredentials = () => this.specificConfig.getCredentials();
await this.do('step-a', { dynamicAction: action });

The action will be persisted in the database and executed in an isolated context. When executed, getCredentials will be overridden with this definition specific to the workflow context.

The result of the await will be the result of the action.
If the final action's state is ActionState.ERROR, the do() method will throw the error — allowing standard error handling using try/catch.

Under the hood

Under the hood, the do method returns a standard JavaScript promise. However this promise does not always resolve.

Let's say we have a workflow with two steps:

export class MyWorkflow extends Workflow {
    define() {
        const actionA = new LongTermAction();
        const result = await this.do('step-a', actionA);
        await this.do('step-b', new MyAction().setArgument(result));
    }
}

Here is the flow of calls that happens.

Repeat and transform

Action level

At the action level, you can configure the repetition using the setRepeat() method. Example:

export class MyWorkflow extends Workflow {
    define() {
        try {
            await this.do(
                'my-action',
                new MyAction()
                    .setArgument({
                        x: 1,
                    })
                    .setRepeat({
                        [ActionState.ERROR]: 2, // repeat twice, so will be executed max. 3 times
                    })
            );
        } catch (err) {
            await this.do(
                'on-error-action',
                new OnErrorAction().setArgument({
                    x: 1,
                })
            );
        } finally {
            //....
        }
        return {
            x: 2,
        };
    }
}

Workflow level

At the workflow level, you can configure the repetition using the repeatDo() method. Example:

export class WorkflowWithRepeat extends Workflow {
    async define() {
        await this.repeatDo(
            'repeatSuccess',
            () => {
                //...do something...
                return Promise.resolve();
            },
            {
                [ActionState.SUCCESS]: 2,
                elapsedTime: 10,
            }
        );

        try {
            await this.repeatDo(
                'repeatOnFailure',
                () => {
                    //...do something...
                    return Promise.reject();
                },
                {
                    [ActionState.ERROR]: 2,
                    elapsedTime: 10,
                }
            );
        } catch (err) {}
        return i;
    }
}

Transformation

The transform() method is a powerful hook that intercepts every Action before it is executed by the Workflow.

It acts as a proxy layer over all Actions that pass through the Workflow engine. You can use it to:

Modify the arguments of any Action;
Replace one Action with another;
Apply conditional logic;
Dynamically set .setRepeat(), .setTimeout(), .setBag(), etc.

This is especially useful when you want to customize or override an Action behavior without changing the Workflow's define() logic.

Examples

Simple example

export class MyWorkflow extends Workflow {
    // The transform method allows you to intercept and modify actions dynamically.
    transform(ref: string, action: Action): Action {
        if (ref === 'my-action') {
            // Override the arguments for the step "my-action"
            return MyAction().setArgument({
                x: 2,
            });
        }

        // Returning `undefined` means the original action instance will be used as-is
        return;
    }

    async define() {
        try {
            await this.do(
                'my-action',
                MyAction()
                    .setArgument({
                        x: 1,
                    })
                    .setRepeat({
                        [ActionState.ERROR]: 2, // Retry up to 2 times on error (executed max 3 times)
                    })
            );
        } catch (err) {
            await this.do(
                'on-error-action',
                OnErrorAction().setArgument({
                    x: 1,
                })
            );
        } finally {
            // You can perform cleanup or additional steps here
        }

        return {
            x: 2,
        };
    }
}

Key Notes

The ref argument passed to transform() matches the name you use in this.do("my-action", ...).
You must return a valid Action instance if you want to replace or modify it.
If transform() returns undefined, the original Action provided in define() will be used.

Use this to:

Inject environment-specific parameters (e.g. test vs. prod);
Dynamically change retry logic or timeouts;
Centralize logic for versioning or conditional behavior.

Inheritance example

export class CustomWorkflow extends BaseWorkflow {
    transform(ref: string, action: Action): Action {
        if (ref === 'notify') {
            // Override the default email step with a custom SMS notification
            return new SendSmsAction().setArgument({
                message: 'This replaces the email notification',
            });
        }
        return;
    }
}

This pattern allows you to:

Reuse shared workflow logic;
Swap or extend individual steps based on context;
Build a hierarchy of workflows with consistent interfaces but customizable behavior.
