Hello world

This is a basic guide to get your first resource working.

Install

Install @orbi-ts/core and @orbi-ts/fuel.

npm install @orbi-ts/core @orbi-ts/fuel --save

Install it with yarn:

yarn add @orbi-ts/core @orbi-ts/fuel

Write your first action

An Action is an object that encapsulate a mutating process.

src/orbits/my-action.ts
import {Action} from "@orbi-ts/core"

export class MyAction extends Action{

    main(){
        console.log("hello");
        this.setResult("hello!")
        return ActionState.SUCCESS;
    }
}

Use a watcher

Sometimes, a mutating process doesn't complete immediately. It may involve delays, external systems, or asynchronous validation. In such cases, Orbits allows you to track progress over time using the watcher() method.

When your main() function returns ActionState.IN_PROGRESS, Orbits will continue to invoke watcher() periodically to determine whether the action has ultimately succeeded, failed, or is still in progress.

src/orbits/my-action.ts
import {Action} from "@orbi-ts/core"

export class MyAction extends Action{

    main(){
        this.setResult("hello!")
        return ActionState.IN_PROGRESS;
    }

    watcher() {
        // In a real scenario, you'd check whether the "hello" mutation
        // has completed (e.g., a message was received, a job succeeded, etc.)
        // For this example, we just simulate success after 10am.
        if (new Date().getHours() > 10) {
            return ActionState.SUCCESS;
        } else {
            console.log("Waiting until after 10am before confirming success...");
            return ActionState.IN_PROGRESS;
        }
    }
}

Using a watcher helps your actions stay reactive and robust, even when their effects unfold over time. This pattern is especially useful when interacting with eventually consistent systems, long-running jobs, or third-party APIs.

Consume your action

Use the action anywhere you want in your app

src/anywhere-in-your-app.ts
  const action = new MyAction();
  await action.save();//the action will be executed in the background.
  await Action.trackActionAsPromise(action, [ActionState.SUCCESS, ActionState.ERROR]);//this line is optional.

info

Configure persistent storage

To store the state of your actions, a connection to a database is required. Currently, only MongoDB is supported. By default, Orbits attempts to connect to a local MongoDB instance (localhost). To use a remote MongoDB instance, provide a full MongoDB connection URI via the ORBITS_DB__MONGO__URL environment variable. Example :

export ORBITS_DB__MONGO__URL='mongodb+srv://orbits:XXXX@myatlas-cluster.mongodb.net/orbits-test?retryWrites=true&w=majority'

tip

To enable verbose logs while debugging, set the logging level to debug:

export ORBITS_LOGGING_LEVEL='debug'

Workflow: a chain of actions

You will quickly want to exploit the result of your action and not just launch a process in background. To do this, you need to write a Workflow.

src/orbits/my-workflow.ts
import {Workflow} from "@orbi-ts/core"
import {MyAction} from "./my-action.js"

export class MyWorkflow extends Workflow{

    IArgument: {
        name : string
    }

    define(){
        const resultOfMyAction = await this.do("hello", new MyAction());
        const name = await this.do("name", ()=>{
            console.log(`${resultOfMyAction}, ${this.argument.name}!`)
            return Promise.resolve(this.argument.name)
        })
        return `${resultOfMyAction}, ${name}!`
    }
}

Of course, you don’t need this level of complexity just to display “hello, name” — this is simply for demonstration purposes. Here, using this.do we ensure that, for each execution of MyWorkflow, the "hello" step is run once and only once. Same, the "name" step is run once and only once. This approach aligns with the SAGA principle.

Consume your workflow

A workflow is an action, so you consume it like an action

src/anywhere-in-your-app.ts
  const workflow = new MyWorkflow().setArgument({name : "John Doe"});
  await workflow.save();//the action will be executed in the background.
  await Action.trackActionAsPromise(workflow, [ActionState.SUCCESS, ActionState.ERROR]);//this line is optional.

Resources : a complete lifecycle

Greetings occurs only once in a day but if you do :

src/consume-workflow.ts
    const workflow1 = new MyWorkflow().setArgument({name : "John Doe"});
    await workflow1.save();//the action will be executed in the background.
    //others processes
    const workflow2 = new MyWorkflow().setArgument({name : "John Doe"});
    await workflow1.save();

the workflow will run twice. How do you do to have it run once ? This is managed by the concept of Resource.

src/orbits/my-resource.ts
    export class MyGreetings extends Resource{
        IArgument: {
            name : string
            date: string
        }

        identity(){
            return `${this.argument.name}-${this.argument.date}`
        }

        defineInstall(){
            //say hello
            await this.do("hello", new MyWorkflow().setArgument({
                name: this.argument.name
            }))
        }

        defineUpdate(){
            //do nothing, I already have seen you
        }

        defineUninstall(){
            //say goodbye
            const goodbye = await this.do("goodbye", ()=>{
                console.log("goodbye")
                return "goodbye ; it was a great day";
            })
            return `${goodbye} ${this.argument.name}`
        }

    }

Consume your resources

A resource is an action, so you consume it like an action

src/anywhere-in-your-app.ts
  const resource = new MyGreetings().setArgument({
    name: "John Doe",
    date: "01-01-01"
  });
  await resource.save();//the action will be executed in the background. the greetings will appear in the console
  await Action.trackActionAsPromise(resource, [ActionState.SUCCESS, ActionState.ERROR]);

  const resource2 = new MyGreetings().setArgument({
    name: "John Doe",
    date: "01-01-01"
  });
  await resource2.save();//the action will be executed but nothing will appear in the console.log, as we already installed the resource
  await Action.trackActionAsPromise(resource2, [ActionState.SUCCESS, ActionState.ERROR]);

  const resource3 = new MyGreetings().setArgument({
    name: "John Doe",
    date: "01-01-01"
  }).setCommand("goodbye");
  await resource2.save();//the action will be executed ; "goodbye" will appear in the console
  await Action.trackActionAsPromise(resource2, [ActionState.SUCCESS, ActionState.ERROR]);

Next Steps

What's Next?

Here are three recommended next steps to continue your journey:

👋 Hello world example - Build your first Orbits application with our step-by-step tutorial and see immediate results
⚙️ Core-concepts - Master the fundamental architecture principles and design patterns that power Orbits
🛤️ Guides - Explore hands-on tutorials ranging from beginner-friendly to advanced implementation techniques
